We have successfully test fit the latest version of our QUADloc harnessbar for the Emira. Overall I'm pleased with it but we are going to add an additional gusset to the outer tabs to make that portion super strong.
I did some math on our Anti-Rotation mechanisms:
- Primary anti-rotation: 1 on each side (two total)
- Each of the bolts that secure this mechanism will take 29,000lbs of force
- Total strength = 58,000lbs of force
- Secondary anti-rotation = 1 on each side (two total)
- Total strength = 6,000 lbs
With two 180lb people in the car, wearing harnesses, they would exert approx. 5,400lbs onto the QUADloc bar in a 30g crash. Our QUADloc will restrain up to 64,000lbs. I’m confident it will not rotate!
We also confirmed our adjustability that eases installation works as expected. This will be a very easy bar to install thanks to the split main bar. It will also ship very easily.
We are now finalizing the costs to manufacture along with the final weights.
